SMT pcb assembly service

pcba service
PCB SMT assembly, including PCB proofing expedited proofing circuit board, single-sided PCB, double-sided circuit boards, multi-layer circuit boards.
Quantity
Contact Now
add to cart

pcba,pcb assembly

One-stop OEM pcb assembly services pcba manufacturer
STG specializes in pcb assembly and processing business, providing electronic components procurement,SMT (surface mount) processing, BGA welding, THT (plug-in) welding, assembly, testing, inspection, packaging to transport and other whole process services.


pcb production
1.NO MOQ
2.24 hours quick turn prototype
3.prototype&mass production
4.on time delivery
5.100% electrical test gurantee
6.competitive price




pcba,pcb assembly



pcb assembly
1.SMT pcb assembly & PTH assembly
2.fine pitch BGA QFN smallest 0201 package
3.Bonding assembly
4.pcba AOI&X-ray inspection
5.pcba ICT function testing
6.no MOQ requirements
7.over 150 speedy samples can be processed within 1
8.working day
9.40 million to 80 million SMT points each month
pcba,pcb assembly




one-stop turnkey service
1.PCBA components sourcing
2.SMT stencil
3.SMT&Through holes assembly
4.PCBA cable assembly
5.PCBA conformal coating
6.PCBA software programming
7.PCBA functional testing
8.PCBA enclosure assembly
9.PCBA customized packaging

pcba,pcb assembly




Introduction of our pcb assembly capability
ArticleDescriptionCapability
Laminate MaterialsFR4, high TG FR4, high frequency, alum, FPC
Board CuttingNumber of layers1-30
Min.thickness for inner layers0.003”(0.07mm)
(Cu thickness are excluded)
Board ThicknessStandard(0.1-4mm±10%)
Min.Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twistno more than 7/1000
Copper WeightOuter Cu weight0.5-4 0z
Inner Cu weight0.5-3 0z
DrillingMin size0.0078”(0.2mm)
Drill deviation±0.002″(0.05mm)
PTH hole tolerance±0.002″(0.005mm)
NPTH hole tolerance±0.002″(0.005mm)
Solder MaskColorGreen,white,black,red,blue…
Min solder mask clearanace0.003″(0.07mm)
Thickness(0.012*0.017mm)
SilkscreenColorwhite,black,yellow,blue…
Min size0.006″(0.15mm)
Component SourcingYes
Tolerance of PCB±5%
Max Size of Finish Board700*460mm
MOQNO MOQ (1pcs)
Surface FinishHASL,ENIG,immersion silver,immersion tin,OSP…
PCB OutlineSquare,circle,irregular(with jigs)
PackageQFN,BGA,SSOP,PLCC,LGA
Sub-assemblyPlastic,metal,screen
Min Line/Space0.075/0.075mm

pcba processing services, including PCB proofing expedited proofing circuit board, single-sided PCB, double-sided circuit boards, multi-layer circuit boards
pcb assembly type.
1.aluminum pcb assembly
2.flexible pcb assembly
3.rigid-flex pcb assembly
4.RF PCB
5.FR4 PCB


PCBA application
Products and services are widely used in automotive, electric power, communications, aerospace, industrial control, computer applications and other fields!
      pcba,pcb assembly          pcba,pcb assembly           pcba,pcb assembly
                 aerospace defense pcba                                        automotive pcba                                       household equipment pcba


     pcba,pcb assembly          pcba,pcb assembly           pcba,pcb assembly
              industrial control pcba                                         medical equipment pcba                                            robot pcb assembly
